Aluminum PCB Manufacturer
● Professional engineering team review; rigorous quality control for every manufacturing stage.
● Advanced testing technologies such as AOI, E-Test, X-RAY, and Impedance Control to ensure premium quality.
● Committed to delivering high-quality products and services at competitive prices, especially for multilayer PCBs.
Need Aluminum PCB Manufacturing?
At MarsPCB, we are dedicated to providing premium-quality aluminum PCBs that have earned the trust of our clients worldwide, particularly in North America and Europe. Our aluminum PCBs are crafted with a metal substrate to offer excellent heat dissipation and feature an FR4 base coupled with an aluminum core, ensuring superior performance for your projects.
Perfect for high-power or precision-sensitive devices, these PCBs efficiently manage heat and improve overall device functionality. As a leading PCB assembly manufacturer, we deliver reliable PCB assembly services that meet all your electronic manufacturing needs.
About Aluminum PCBs
Aluminum PCBs are built with layers of silkscreen, solder mask, and copper, along with a metal substrate that replaces the fiberglass commonly found in traditional boards.
The base material of aluminum PCBs integrates an FR4 layer and an aluminum core, offering exceptional heat conduction capabilities. These boards are ideal for high-power or tight-tolerance applications due to their superior thermal properties, which help in reducing thermal expansion, unlike copper or other materials.
The thermal layer in aluminum PCBs is designed to effectively dissipate heat, ensuring that your components stay cool and continue to operate efficiently. Partnering with a reliable metal-core PCB manufacturer can ensure optimal performance tailored to your unique thermal and mechanical needs.
Aluminum PCBs: Key Benefits
sing aluminum in your PCB manufacturing can enhance heat dissipation, minimizing thermal stress and circuit degradation.
Compared to fiberglass or ceramic materials, aluminum offers better durability and strength for electronic devices.
Aluminum is fully recyclable and non-toxic, making it a sustainable option. Its lightweight nature and ease of assembly contribute to reduced energy consumption during manufacturing.
Aluminum PCBs are known for their durability and light weight, offering the ideal combination of strength and resilience without adding unnecessary weight.
Thanks to aluminum's sturdy properties, these PCBs are resistant to damage during handling, transportation, and daily use, making them ideal for high-reliability applications.
Compared to other metal options, aluminum provides a more cost-efficient solution without compromising quality, making it ideal for high-volume production.
Aluminum excels at transferring heat away from sensitive components, enhancing the longevity and efficiency of your electronic devices by keeping temperatures in check.
Aluminum PCB Materials and Structure
Aluminum PCBs are a cost-effective solution for high-performance electronics. Available in single-layer, double-layer, and multi-layer designs, they are perfect for applications like LED lights, solar panels, and more.
Common aluminum substrate materials include:
- 6061: A versatile aluminum alloy with good strength and machining properties.
- 5052: Known for its excellent bending properties and resistance to corrosion.
- 3003 & 1100: Pure aluminum with excellent thermal conductivity.
The dielectric material used in our aluminum PCBs is a specialized polymer filled with ceramics, ensuring reliable insulation.
Rigid and Flexible Aluminum PCBs
At Mars PCB, we offer both rigid and flexible aluminum PCBs:
- Rigid Aluminum PCBs: These are commonly used in industrial, automotive, and communication applications. Available in 1-layer, 2-layer, and 4-layer designs.
- Flexible Aluminum PCBs: Ideal for applications like flexible LED lighting, where the PCB needs to bend without compromising thermal performance.
We support both prototype and mass production of these PCBs to meet the specific needs of your project.
The Build Layout of Aluminum PCBs
Copper Foil Layer
- This layer is typically thicker than standard copper-clad laminates, usually ranging from 1 oz to 10 oz. The increased thickness improves the board’s current-carrying capacity and overall performance.
Dielectric Layer
- The dielectric layer, which ranges from 50 μm to 200 μm in thickness, offers excellent thermal conductivity. It is crucial for ensuring low thermal resistance, making it ideal for heat-sensitive applications.
Aluminum Base
- The third layer is an aluminum base, known for its high thermal conductivity, which ensures efficient heat dissipation and robust mechanical performance.
Aluminum Base Membrane Layer
- This protective layer prevents scratches and damage to the aluminum surface. Depending on the application, the membrane can be heat-resistant, with options up to 250°C.
Mars PCB's Production Capabilities
Feature | Capabilities |
Material: | FR4, aluminum core, copper core, Rogers, flex, and more. |
Surface Finishing: | ENEPIG, immersion gold, immersion silver, OSP, and more. |
Testing: | AOI，E-TEST and Fly Probe Testing for enhanced quality control. |
Thermal Conductivity: | 1.0 W/(mk), 2.0 W/(mk), 3.0 W/(mk), 5.0 W/(mk), 7.0 W/(mk) |
Board Thickness: | 0.4-3.2 mm |
Silkscreen: | Available in black, white, red, yellow, green, matte black, and purple. |
Build Time: | Standard lead time of three days. |
Solder Mask: | Available in various colors, including matte green, black, yellow, white, and red. |
Base Material: | Rogers, FR4, aluminum, flex-rigid, and more. |
Via Process: | Supports standard vias, tented vias, and plugged vias. |
Minimum Hole Size: | 0.8 mm |
Copper Finish: | 1-4 oz |
Minimum Spacing: | 4 mil |
Types of Aluminum PCBs
Aluminum PCBs come in several variations, each tailored to specific applications. Here’s a closer look at the different types
Flexible Aluminum PCBs
These PCBs combine excellent flexibility, high electrical insulation, and outstanding thermal conductivity. Ideal for designs that require bendable circuit boards, they offer the perfect balance between durability and performance.
Flexible aluminum PCBs are typically used in applications where space constraints and weight are important factors, such as in automotive lighting, medical devices, and compact consumer electronics.
Through-Hole Aluminum PCBs
Through-hole aluminum PCBs are engineered for high-voltage and high-current applications, providing excellent electric insulation. These PCBs feature pre-drilled holes, which are filled with dielectric material to ensure electrical isolation.
These boards are commonly used in power supply units, automotive systems, and devices where reliable electrical conductivity and thermal management are essential.
Multilayer Aluminum PCBs
Multilayer aluminum PCBs consist of multiple layers of thermally conductive dielectric materials. This type of PCB is specifically designed for advanced thermal management in high-power applications.
These boards offer enhanced heat dissipation capabilities, making them ideal for sophisticated electronic systems in industries such as automotive, telecommunications, and industrial equipment.ecific needs of your project.
Hybrid Aluminum PCBs
Hybrid aluminum PCBs are created by combining aluminum with non-thermal materials such as FR4 or other composites. These boards provide a unique solution where both thermal and mechanical stability are required.
Ideal for applications that need both heat dissipation and structural integrity, hybrid aluminum PCBs are commonly used in high-performance LED lighting systems, power electronics, and automotive applications.
Why Choose Mars PCB for Aluminum PCBs?
Mars PCB offers high-quality materials for multilayer PCBs, including FR4, rigid-flex, flexible, aluminum, copper, and ceramic. For FR4 boards, we use high-Tg material to ensure durability and performance.
Mars PCB has specialized production lines, including advanced immersion gold technology, providing industry-leading capabilities in multilayer PCB manufacturing.
Our experienced engineers can optimize your multilayer PCB design and provide personalized support to meet your specific needs, ensuring a smooth production process from start to finish.
Mars PCB follows a rigorous ISO-based quality management system. Our multilayer PCBs are certified to ISO 9001, IATF 16949, RoHS, REACH, UL, and IPC standards, guaranteeing the highest quality and reliability.
Mars PCB provides end-to-end services, from PCB design and prototyping to assembly, testing, and delivery. We offer flexible, customized solutions based on your project requirements.
Mars PCB offers a range of shipping options, including air, sea, and rail services through trusted carriers like DHL, FedEx, and UPS. We also allow you to choose your preferred freight forwarder.
Bringing Your PCB Designs to Life
At MarsPCB, we’re here to transform your ideas into high-quality, reliable PCB solutions. With over 15 years of industry experience, our team ensures your designs are brought to life with precision and efficiency.
