FAQs
PCB Manufacturing FAQs
A high-speed circuit typically operates with clock frequencies above 50 to 100 MHz or with signal rise times below 1 nanosecond. These circuits require special design rules to maintain signal integrity and prevent electromagnetic interference.
High-speed signals have faster rise times and higher frequencies compared to low-speed signals, resulting in more complex behavior on the PCB. Low-speed signals are simple point-to-point connections, while high-speed signals are transmission lines with impedance control and meticulous PCB routing.
The top three crucial steps in PCB design and layout are:
Proper Component Placement:Optimizes signal flow and minimizes trace lengths.
Careful Stackup Design:Ensures controlled impedance and signal integrity.
Efficient Trace Routing:Addresses signal integrity and EMI issues through optimal routing paths.
High-frequency PCBs can manage signals up to several hundred GHz in specialized applications. However, most commercial high-frequency PCBs operate between a few GHz to tens of GHz, depending on the materials and design used.
High-speed PCBs are designed for rapid digital signal transitions, while high-frequency PCBs are tailored for efficient analog or RF signal transmission at elevated frequencies.
Cavity PCBs reduce size and weight, increase assembly density, improve performance and reliability, and enhance heat dissipation, making them ideal for high-performance applications.
Manufacturing involves design and engineering, material selection, precision machining using CNC or laser technology, layer alignment and bonding, and circuit patterning and etching.
Cavity PCBs excel in RF/microwave systems, telecommunications, automotive electronics, power amplifiers, and high-speed computing applications where space, performance, and thermal management are critical.
They reduce signal path lengths, minimize parasitic effects, improve grounding, and enable better isolation between signal paths, resulting in enhanced performance for high-frequency applications.
PCB Assembly FAQs
Assembly can take 1–15 days, depending on order volume, component sourcing, and design complexity.
Expect to submit Gerber or ODB++ data, BOM, pick-and-place files, plus any specialized assembly instructions.
It’s possible, but revisions after assembly starts often bring higher costs. Early-stage changes are simpler and cheaper.
SMT can be done for prototypes, but it might require a specialized stencil and placement file, making it pricier for small runs.
SMD stands for “Surface Mount Device,” referring to components designed for surface mounting.
SMT describes the process, while SMD refers to the actual components placed on the board.
Yes, hybrid assemblies are common when certain parts demand through-hole reliability and others require miniaturization.
We can assemble parts of nearly any size, from small passives (like 0201) up to large connectors. We also deal with BGAs (ball grid arrays) and advanced chip packages.
We provide both leaded and lead-free solder. If you need products aligned with RoHS or environmental regulations, we’ll use lead-free materials. For specialized gear like automotive or defense projects, leaded solder might be a better choice.
High-volume assembly often reduces the per-unit cost by eliminating repetitive prototyping. Thanks to streamlined automation, turnaround is swift, and the entire batch adheres to consistent specifications. Scaling up lowers the overall chance of errors since the design phase is verified just once before bulk production.
Quality originates from selecting a certified manufacturer. Mars PCB follows recognized industry guidelines and acquires components from vetted sources. We also rely on AOI, X-ray scanning, and stringent functional tests—ensuring each board meets performance standards before shipment.
HDI (High-Density Interconnect) PCBs incorporate more intricate layering and narrower trace widths for denser circuits. They employ microvias and buried vias, delivering better signal performance and reduced stray impedance compared to typical boards. HDI designs are frequently preferred for advanced or space-critical applications.
The solder joints lie beneath the package, making defects or misalignments harder to detect. Also, reworking a BGA can be tricky because direct access to the solder spheres is limited.
- Signal Routing: Keep leads short for minimal signal interference, especially for high-speed paths.
- Thermal Management: Allocate enough space for thermal vias, heatsinks, or airflow.
- Accessibility: Leave a buffer zone around BGAs for inspection or repairs.
Layer count varies with pin numbers and design complexity. Simple low-pin BGAs may suffice with 2 to 4 layers, while complex, high-pin devices could require 6 or more. Discuss layer requirements with your manufacturer to ensure functionality and production feasibility.
